Ottonius PSK1 Small Digital Display Pressure Sensor PSK1-C1C-R1/8

Name: Ottonius PSK1 Small Digital Display Pressure Sensor PSK1C1CR18
Brand: Ottonius
Price: 14.8 USD

Brand Name : Ottonius

Model Number : PSK1-C1C-R1/8

Certification : CE/CCC

Place of Origin : EU

MOQ : 5

Price : 14.8 USD

Payment Terms : T/T

Delivery Time : 5 days

Packaging Details : Carton

Series : PSK1

Engine Size : STD

Stock : In Stock

Mounting Type : Through Hole

Part Name : Pressure Sensor

Output Resistance : 700±5Ω

Description : SENSOR CURRENT HALL 130A AC/DC

Item No : 3BSE008516R1

Auxiliary Power Supply : 30VDC

Polarization : Bidirectional

Keywords : Al2o3 Alumina Ceramic Parts

Accuracy : ±0.01mm

Size : 30(W) x 21.3(D) x 30(T) mm

Printing Type : Offset Printing Machine

Replacement No : Excavator

Contact Now

Ottonius PSK1 Small Digital Display Pressure Sensor PSK1-C1C-R1/8

Product Specifications

Attribute	Value
Series	PSK1
Engine Size	STD
Stock Status	In Stock
Mounting Type	Through Hole
Part Name	Pressure Sensor
Output Resistance	700±5Ω
Description	SENSOR CURRENT HALL 130A AC/DC
Item No	3BSE008516R1
Auxiliary Power Supply	30VDC
Polarization	Bidirectional
Accuracy	±0.01mm
Dimensions	30(W) x 21.3(D) x 30(T) mm
Replacement No	Excavator

Technical Specifications

Specification	Details
Pressure Type	Compound Pressure
Rated Pressure Range	-100 ~ 1,000 kPa; -100.0 ~ 100.0 kPa
Set Pressure Range	-103 ~ 1,030 kPa; -103.0 ~ 103.0 kPa
Withstand Pressure	1.5 MPa; 500 kPa
Applicable Gas	Air, non-corrosive, non-flammable gas
Power Supply Voltage	12 - 24 VDC ± 10%, Ripple P - P ≤ 10%
Current Consumption	≤ 30 mA (no load)
Control Output	Output Type: NPN or PNP collector open output Load Current: ≤ 125 mA Internal Pressure Drop: ≤ 1.0 V Response Time: ≤ 2.5 ms
Display	White (Sampling speed: 200 ms, 500 ms, 1000 ms optional) Display Accuracy: ± 1% F.S. ± 1 digit Repeat Error: ± 0.3% F.S. ± 1 digit
Operating Environment	Protection Grade: IP 40 Operating Ambient Temperature: 0 ~ 50°C Storage Temperature: -10 ~ 60°C
Connector Specification	Lead wire (oil-resistant PVC, Ø4 mm, 3 cores, 0.15 mm²)
Pressure Port	R1/8
Material	Front Housing: PA66 + G15% Rear Housing: PA66 + G15% Pressure Port: Brass - Nickel Plated
Certification	CE
Weight	≈ 62 g (including 2m wire)

Product Dimensions

Ottonius PSK1 Small Digital Display Pressure Sensor PSK1-C1C-R1/8

Installation Diagram

Product Tags:

Small Digital Display Pressure Sensor

PSK1-C1C-R1/8

Ottonius PSK1 Small Digital Display Pressure Sensor PSK1-C1C-R1/8 Images
